OCTA CORE ANDROID BOX BASED ON AMLOGIC S912 support Wifi6 and POE - DM39
DM39 is an Octa core android TV box based on Amlogic S912 chipset with latest WiFi 6 802.11 ax technology and POE for power and network 2 in 1 supply, so easy to deploy any place free of extra power adapter. Powerful Octa core CPU and Mali T family GPU to make sure high definition movie,music,game entertaiment. In addition, next generation S922 is optional.
SPECIFICATION
DESCRIPTION
SPECIFICATION
| HARDWARE | |
|---|---|
| CPU | Amlogic S912 Octa-Core ARM /S922X Cortex-A53 up to 2.0GHz |
| GPU | ARM Mali-820MP3 GPU 750Ghz+ |
| DDR3/DD4 | 2GB or 3GB |
| Flash | 16GB or 32GB EMMC |
| WiFi | 802.11 b/g /n ( 2.4G) , Dual band optional |
| Bluetooth 4.0 | Included |
| Bluetooth RCU | Support Google voice search |
| Color | Black |
| Power | DC input 5V/2A |
| SOFTWARE | |
|---|---|
| Android OS | AOSP 7.1.2/9.0 |
| Video/Picture encode | UHD 4K 60fps HW decode,FHD 1080P 60fps,H.265 10-bit, H.264,VC-1,MPEG1/2/4 AVS+,VP8/VP9 HW decode |
| Audio decode/encode | MP3,AAC,WMA,RM,FLAC,OGG,AC-3, Dolby |
| Language | Multi-language |
| DRM(optional) | PlayReady/Widevine/HDCP 2.2 |
| Pre-install | PlayStore, YouTube, Netflix, Kodi, Movie Player, PrimeVideo, Chrome browser |
| I/O | ||||
|---|---|---|---|---|
| 1* HDMI | Up to 4K | |||
| 2* USB | High speed USB 2.0 | |||
| 1* Ethernet | RJ45 | |||
| 1* OTG | Data transportation | |||
| 1* AV output | Mini jack | |||
| 1* Power input | 5V/2A |
| ACCESSORIES | |
|---|---|
| Gift box | √ |
| Power adapter charger | √ |
| HDMI cable | √ |
| IR remote control | √ |
| User Manual | √ |
